Butterfly Valve
We can supply different types of valve and fitting for petrochemical, pharmaceutical, power station, sanitary and process industries.
| Brand | KSTN | TPCM |
| Country of Original | Taiwan | China |
| Warranty | 1 Yr | 1 Yr |
| Description | Butterfly Valve | Butterfly Valve |
| Type | Lug/ Wafer | Lug/ Wafer/ Grooved |
| Material (body) | SS316/ SS304/ WCB/ DI/ CI | DI (FBE coating) |
| Material (stem) | SS316/ SS304/ SS410 | SS431 |
| Material(disc+seat) | SS316/ SS304/ DI/ Bronze + EPDM/ Viton | DI + EPDM |
| Rating | JIS 10K/ 16K, DIN PN10/ 16, ANSI 125/ 150lb | DIN PN16, ANSI 300lb |
| Operating Temp. | 150'C | 100'C |
| Operating Press. | 10/16bar, 125/150psi | 16bar, 300psi |
| Available Size | 2" to 24" | 2" to 12" |
| Application | Opening/ Isolating process pipelines (air, water, ) | Opening/ Isolating process pipelines (fire water, ) |
| Accessories | Lever/ Gear operated handle, with ISO 5211 mounting pad, with electric/ pneumatic/ hydraulic actuator | Gear operated handle, with ISO 5211 mounting pad, with flag type position indicator |
| Standard | Factory | EN 593/ BS 5155/ UL 1091/ MSS SP-67 |
| Certified/Tested | EC/ ISO | UL Listed/ FM Approved |
| DOWNLOAD DATASHEET | DOWNLOAD DATASHEET |
Globe Valve
We can supply different types of valve and fitting for petrochemical, pharmaceutical, power station, sanitary and process industries.
| Brand | KSTN | KSTN |
| Country of Original | Taiwan | Taiwan |
| Warranty | 1 Yr | 1 Yr |
| Description | Globe Valve w/ BSP thread | Globe Valve w/ flange |
| Type | OS & Y | OS & Y |
| Material (body) | F11/12/ SS304/316/ F304/316 | CI/ CS/ DI/ SS316/304 |
| Material (stem) | SS304/316/410 | CS/ SS304/316/410 |
| Material (disc) | SS304/316 | CS/ SS304/316 |
| Rating | 200/ 300/ 1000WOG | JIS 10K/ 20K, DIN PN16, ANSI CL150/ 300/ 600lb |
| Operating Temp. | 150°C, | 150°C, |
| Operating Press. | 200/300/600psi | 150/250/300/600psi |
| Available Size | 1/4" to 2" | 1/2" to 12" |
| Application | Opening/ Isolating process pipelines (stream, gas, ) | Opening/ Isolating process pipelines (stream, gas, ) |
| Accessories | ||
| Standard | Factory | Factory |
| Certified/Tested | EC/ ISO | EC/ ISO |
| DOWNLOAD DATASHEET | DOWNLOAD DATASHEET |
Check Valve
We can supply different types of valve and fitting for petrochemical, pharmaceutical, power station, sanitary and process industries.
| Brand | KSTN | KSTN |
| Country of Original | Taiwan | Taiwan |
| Warranty | 1 Yr | 1 Yr |
| Description | Check Valve w/ BSP thread | Check Valve w/ flange |
| Type | Swing/ Lift/ Piston | Swing/ Lift/ Dual Plate/ Wafer/ Silent |
| Material (body) | Brass/ SS304/316 | CI/ CS/ FS/ SS304/316 |
| Material (pin) | SS304/316 | SS304/316 |
| Material (disc) | Brass/ SS304/316 | CS/ SS304/316 |
| Rating | 200/ 300/ 1000WOG | JIS 10K/20K, DIN PN16/40, ANSI CL150/300 |
| Operating Temp. | 150 °C, | 150 °C, |
| Operating Press. | 200/ 300/ 1000psi | 150/ 250/ 300/ 600psi |
| Available Size | 1/4" to 2-1/2" | 1/2" to 16" |
| Application | One direction flow in the piping system | One direction flow in the piping system |
| Standard | Factory | Factory |
| Certified/Tested | EC/ ISO | EC/ ISO |
| DOWNLOAD DATASHEET | DOWNLOAD DATASHEET |
Gate Valve
We can supply different types of valve and fitting for petrochemical, pharmaceutical, power station, sanitary and process industries.
| Brand | KSTN | KSTN |
| Country of Original | Taiwan | Taiwan |
| Warranty | 1 Yr | 1 Yr |
| Description | Gate Valve w/ BSP thread | Gate Valve w/ flange |
| Type | Rising Stem & Non-Rising Stem | |
| Material (body) | Brass/SS304/316 | CI/ CS/ FS/ SS304/316 |
| Material (stem) | Brass/SS304/316 | SS304/316 |
| Material (disc) | Brass/SS304/316 | CS/SS304/316 |
| Rating | 300WOG/1000WOG | JIS 10K/20K, DIN PN16/40, ANSI CL150/300 |
| Operating Temp. | 150/ °C, | 150/ °C, |
| Operating Press. | 200/300/1000psi | 150/250/300/600psi |
| Available Size | 1/2" to 12" | 1/2" to 12" |
| Application | Opening/Isolating in the piping system | Opening/Isolating in the piping system |
| Standard | Factory | Factory |
| Certified/Tested | EC/ ISO | EC/ ISO |
| DOWNLOAD DATASHEET | DOWNLOAD DATASHEET |
Ball Valve
We can supply different types of valve and fitting for petrochemical, pharmaceutical, power station, sanitary and process industries.
| Brand | KSTN | KSTN |
| Country of Original | Taiwan | Taiwan |
| Warranty | 1 Yr | 1 Yr |
| Description | Ball Valve w/ BSP thread | Ball Valve w/ flange |
| Type | 1PC/ 2PC/ 3PC (full bore) | 1PC/ 2PC/ 3PC (full bore) |
| Material | Brass/ SS304/316 | CI/ CS/ FS/ SS304/316 |
| Rating | 250WOG/ 1000WOG | JIS 10K/20K, DIN PN16/40, ANSI CL150/300 |
| Operating Temp. | 150/ °C, | 150/ °C, |
| Operating Press. | 250/ 1000psi | 150/ 250/ 300/ 600psi |
| Available Size | 1/4" to 3" | 1/2" to 12" |
| Application | Opening/Isolating in the piping system | Opening/Isolating in the piping system |
| Standard | Factory | Factory |
| Certified/Tested | EC/ ISO | EC/ ISO |
| DOWNLOAD DATASHEET | DOWNLOAD DATASHEET |
